YY8100sa All-in-One Stacked Home Battery Backup Power 5.12kwh
Features:
1.Compact All-in-One Design: The YY48100SA model offers a comprehensive solution with its stacked off-grid battery system. Its compact design integrates all necessary components into one unit, saving space and simplifying installation.
2.High Energy Efficiency: With a 5.12kWh system energy range and a LiFe4PO4 battery type, this system ensures efficient energy storage and delivery. Customers can rely on consistent performance and optimal energy utilization.
3.Versatile Connectivity Options: Equipped with communication ports including CAN, RS485, and RS232, this system enables seamless integration with various monitoring and control systems. Customers can easily manage and monitor their energy usage remotely.
4.Robust Protection Features: Rated at IP20 protection level, the YY48100SA provides reliable protection against dust and solid objects, making it suitable for diverse environmental conditions. Customers can trust in the durability and longevity of their investment.
5.Flexible Grid Connection: Offering the option for grid connection, this system provides customers with flexibility in energy management. Whether as a standalone off-grid solution or integrated with the grid, users have the freedom to adapt to their specific energy needs and circumstances.
Basic parameters:
Batteries materials：Lithium iron phosphate
Series parallel mode (S series, P parallel)：16S1P
Nominal voltage：51.2V
Nominal capacity:100Ah
Size（mm）：700*410*155mm
Weight：50kg
Color: Optional
Parallel support: Parallel terminals are supported
Output port mode：terminal
Charging way：CC/CP/VP
Charging current：0.2C(standard）
Maximum charging current：Max0.5C @25°C
Charge cut-off voltage：58.4V/CELL
Discharge way：CC/CP/VP
Discharge current：0.5C
Maximum discharge current：Max1.2C @25°C
Discharge cut-off voltage：44.8V
According to：LCD
Communication interface：RS485/RS232/CAN
Charging operating temperature：charging:0~+50°C
Discharge operating temperature：discharge:-20~+55°C
The quality assurance period：36 months
Scope of application: hospital, bank data center, wall-mounted home, enterprise energy storage backup power supply, wind complementary system, office, military, base station and other uninterrupted energy storage power supply.
